* Multi-heads are ideally suited to general and small batch production runs of components having equally spaced holes where single spindle set-ups prove uneconomic * This 2 spindle head has a range from 13.5 - 73.5mm * Flange mount to machine * Drive dog options: MT 1,2,3,4 * Reversable * Coller chuck with ER8 collets * Suitable for tapping operations * Other configerations available on request

* Multi-heads are ideally suited to general and small batch production runs of components having equally spaced holes where single spindle set-ups prove uneconomic * This 2 spindle head has a range from 36 - 164mm * Flange mount to machine * Drive dog options: MT 1,2,3,4 * Reversable * Suitable for tapping operations * Other configerations available on request

* This collet is to suit the T-1231 Multi spindle head *

* This is the mounting diagram when fitting to a drilling machine with Morse Taper spindle
