| Drill Capacity (mm) | 40 |
|---|---|
| Tapping Capacity (mm) | M24 |
| Table Size (mm) | 560 x 560 |
| Speeds (no.) | 12 |
| Speed Range (rpm) | 50 – 1450 |
| Spindle Taper | MT4 |
| Quill Diameter (mm) | 75 |
| Quill Stroke (mm) | 180 |
| Swing (mm) | 680 |
| Column Diameter (mm) | 150 |
| Motor (kW) | 1.5 |
| Voltage (V) | 415 |
| Weight Nett / Gross (kg) | 550 |
| Volume (m³) | 1.5266 |
| Packing Size L x W x H (mm) | 2250 x 590 x 1150 |
Description
SKU : DMC359180
Price per Unit
$4,999.00 (Exc GST)
$5,748.85 (Inc GST)
FEATURES:
* Heavy duty drilling machine for industrial use.
* Equipped with power feed on the quill with 2 feed rates.
* Automatic drift release.
* Feed is controlled by electromagnetic clutch.
* Rise and fall table with 360° rotation and +/- 90° tilt.
* Fitted with tapping switch.
* The electrical system has a short circuit and overload protection.
| Weight | 550 kg |
|---|---|
| Dimensions | 2.25 × 0.59 × 1.15 cm |
Specifications
