| Capacity (mm) | 40 |
|---|---|
| Table Size (mm) | 470 x 470 |
| Speeds (no.) | 6 |
| Speed Range (rpm) | 50 – 1250 |
| Spindle Taper | MT4 |
| Tapping Capacity | M20 |
| Quill Stroke (mm) | 110 |
| Swing (mm) | 540 |
| Column Diameter (mm) | 115 |
| Motor (kW) | 1.125 |
| Voltage (V) | 415 |
| Weight Nett / Gross (kg) | 310/ 350 |
| Volume (m³) | 1.0974 |
| Packing Size L x W x H (mm) | 760 x 760 x 1097 |
Description
SKU : DMC359152
Price per Unit
$4,500.00 (Exc GST)
$5,175.00 (Inc GST)
FEATURES:
* Heavy duty geared head drilling machine.
* Tilting head and rotating table.
* Heavy column and base to give this machine rigidity.
* Good spindle travel.
* Fitted with coolant system with fluid resevoir in the base of the machine.
* Automatic feeding.
| Weight | 350 kg |
|---|---|
| Dimensions | 0.76 × 0.76 × 1.9 cm |
Specifications
Description
Reviews (0)
Shipping & Delivery
