| Description | Hydraulic Flange Spreader |
|---|---|
| Model | HHP-1054 |
| Output Force (Ton) | 10 |
| Max Flange Thickness (mm) | 2 x 92 |
| Stud Size (mm) | 31 x 41 |
| Standard Wedge Size (mm) | 3 – 28 |
| Stroke (mm) | 54 |
| Weight (kg) | 14 |
| Volume (m³) | 0.0139 |
Description
SKU : HP-300405
Price per Unit
$440.00 (Exc GST)
$506.00 (Inc GST)
FEATURES:
* This hydraulic flange spreader has a trough bolt capacity of 31.0 to 41.0mm.
* Adjustable jaw widths from 70 to 216mm to suit a wide range of applications.
* Single action spring return.
* Supplied with 3/8 male coupler.
* To suit hydraulic pump with 700 bar capacity.
| Weight | 14 kg |
|---|
