MODEL | HSH 6MM X 3200 |
---|---|
CONTROLLER | Estun E-21S |
SHEARING CAPACITY | 6mm Mild Steel |
BLADE LENGTH | 3200mm |
RAKE ANGLE VARIABLE | N.A. |
MAX RAKE ANGLE | N.A. |
MIN RAKE ANGLE | N.A. |
NO HOLDDOWN | 15 |
HOLDING FORCE | 20 bar |
BACK GAUGE | 990mm |
MOTOR | 7.5 Kw |
LENGTH | 3840mm |
WIDTH | 2320mm |
HEIGHT | 1620mm |
WEIGHT NETT/GROSS | 6500kg |
VOLUME | 15.96cm |
PACKING SIZE L x W x H | 3800 x 2100 x 2000mm |
Description
SKU : SRH132223
Price per Unit
$33,000.00 (Exc GST)
$37,950.00 (Inc GST)
FEATURES:
* This Benzel 6.0mm x L3200mm swing beam type
* Heavy construction with Motorised Back gauge motor is driven with Invertor
* Maximum back gauge travel is 900mm and comes with ball screw for total accuracy
* This machine is fitted with Estun E-245 controller for easy effective cutting control
* Fitted with photo sensor protection at the rear of this machine
Weight | 6500 kg |
---|---|
Dimensions | 3.8 × 2.1 × 2 cm |
Specifications
Description
Reviews (0)
Be the first to review “HYDRAULIC GUILLOTINE: BENZEL 6MM X 3200MM” Cancel reply
Shipping & Delivery
Related products
HYDRAULIC GUILLOTINE: BENZEL 4MM X 3200MM
SKU:
SRH132220
$29,000.00
* This Benzel 4.0mm x L3200mm guillotine is the variable rake type
* Heavy construction with Motorised Back gauge motor is driven with Invertor
* Maximum back gauge travel is 900mm and comes with ball screw for total accuracy
* This machine is fitted with the Estun E-245 controller for easy and effective cutting control
* Fitted with photo sensor protection at the rear of this machine *
HYDRAULIC GUILLOTINE: BENZEL 6MM X 4200MM Swing Beam
SKU:
SRH132224
$39,500.00
* This Benzel 6.0mm x L4200mm guillotine is a Swing Beam type
* Fixed Rake 1.5 degs.
* Heavy construction with Motorised Back gauge motor is driven with Invertor
* Maximum back gauge travel is 900mm and comes with ball screw for total accuracy
* This machine is fitted with the Estun E-10S controller for easy and effective cutting
* Fitted with photo sensor protection at the rear of this machine
HYDRAULIC GUILLOTINE: BENZEL 8MM X 3200MM Swing Beam
SKU:
SRH132225
$42,000.00
HYDRAULIC GUILLOTINE: HSH 6MM X 4200MM VARIABLE RAKE
SKU:
SRH132226
$42,000.00
HYDRAULIC GUILLOTINE: HSH 20MM X 3200MM VARIABLE RAKE
SKU:
SRH132236
$65,900.00
HYDRAULIC GUILLOTINE: HSH 12MM X 4000MM VARIABLE RAKE
SKU:
SRH132238
$56,000.00
HYDRAULIC GUILLOTINE: CNC 4MM X 2500MM VARIABLE RAKE
SKU:
SRH132244
$0.00
HYDRAULIC GUILLOTINE: CNC 6MM X 3200MM VARIABLE RAKE
SKU:
SRH132246
$48,200.00
