| Swing Over Bed (mm) | 660 |
|---|---|
| Swing Over X-slide (mm) | 420 |
| Swing Over Gap (mm) | 870 |
| Between Centres (mm) | 2,000 |
| Bed Width (mm) | 405 |
| Spindle Nose | D1-8 |
| Speeds (no.) | 12 |
| Speed Range (rpm) | 36 – 1,600 |
| Spindle Bore (mm) | 105 |
| Spindle Taper | MT5 |
| Metric Threading (M) | 1 – 14 |
| Imperial Threading (tpi) | 2 – 28 |
| Tailstock Taper | MT5 |
| Tool Height (mm) | 25 |
| Motor (kW) | 11 |
| Voltage (V) | 415 |
| Weight Nett / Gross (kg) | 3,455kg/ 4,005 |
| Volume | 7.7478cm |
| Packing Size L x W x H (mm) | L 3,750m x W 1,150 x H 1,950 |
Sold out
Description
SKU : L--120441
Price per Unit
$34,000.00 (Exc GST)
$39,100.00 (Inc GST)
FEATURES:
* Supersonic frequency hardened bedways.
* Hardened & ground headstock gears.
* Triple headstock spindle bearings.
* 105mm spindle bore for turning large shafts.
* Fitted with a powerful 9kW motor.
* No gear changing required to cut metric & imperial threads.
* Fitted with Sino 2 axis digital readout, taper turning attachment & quickchange toolpost.
| Weight | 4005 kg |
|---|---|
| Dimensions | 3.455 × 1.15 × 1.95 cm |
