Swing Over Bed (mm) | 660 |
---|---|
Swing Over X-slide (mm) | 460 |
Swing Over Gap (mm) | 860 |
Between Centres (mm) | 2660 |
Bed Width (mm) | 480 |
Spindle Nose | D-1-11 |
Speeds (no.) | 16 |
Speed Range (rpm) | 10 – 1395 |
Spindle Bore (mm) | 105 |
Spindle Taper | MT8 |
Metric Threading (M) | 0.2 – 14.0 |
Imperial Threading (tpi) | 2 – 72 |
Tailstock Taper | MT6 |
Motor (kW) | 11.25 |
Voltage (V) | 415 |
Weight Nett / Gross (kg) | 3800 / 4300 |
Availability : Enquire Now
Price per Unit
ex-gst
$0.00Inc-gst
$0.00LATHE: JESSEY GENERAL 660X3000 (TAIWAN)
Description
SKU : L--110170
Price per Unit
$0.00 (Exc GST)
$0.00 (Inc GST)
FEATURES:
* Rigid construction beds are induction hardened and precision ground.
* Harden and ground spindle & gears in headstock for high speed running with low noise.
* Fitted with magnetic brake, and Matrix clutch system.
* Both axes have rapid power feed fitted for quick positioning.
* Rigid tailstock with two speed quill plus rack and handle positioning.
* Front draw chip tray for easy cleaning.
* One-shot oil pump on saddle provides excellent slideways central lubrication.
* Comprehensive range of metric, imperial, diametral & modular threads.
* Made in Taiwan.
Weight | 4300 kg |
---|
Specifications
Description
Reviews (0)
Be the first to review “LATHE: JESSEY GENERAL 660X3000 (TAIWAN)” Cancel reply
Shipping & Delivery
Related products
LATHE: L22 GM6256 560 X 1000 X 80MM BORE
SKU:
L--120028
$18,500.00
* Precision ground & supersonic frequency hardened bedways, with double wall structure for super rigidity.
* Highly accurate & rigid spindle system.
* Optimized design of the main drive, with hardened & ground headstock gears.
* Fitted with 2 axis digital readout, taper turning attachment & quickchange toolpost.
* Over 200 thread cutting options available, in metric, whitworth, module & DP, with no gear changing required.
* Adjustable auto stop mechanism for longitudinal travel.
* Gap bed for larger diameter work pieces.
LATHE: L22 GM6256 560 X 1500 X 80MM BORE
SKU:
L--120029
$23,800.00
* Precision ground & supersonic frequency hardened bedways, with double wall structure for super rigidity.
* Highly accurate & rigid spindle system.
* Optimized design of the main drive, with hardened & ground headstock gears.
* Fitted with 2 axis digital readout, taper turning attachment & quickchange toolpost.
* Over 200 thread cutting options available, in metric, whitworth, module & DP, with no gear changing required.
* Adjustable auto stop mechanism for longitudinal travel.
* Gap bed for larger diameter work pieces.
LATHE: CWA61100 1000 X 8000 X 105MM BORE
SKU:
L--120156
$145,000.00
* This CWA61100 lathe offers precision ground & supersonic frequency hardened bedways.
* Double wall structure provides super rigidity and accuracy.
* Extra large 105mm spindle bore.
* Optimised design of the main drive.
* Precision ground headstock gears.
* Machine operation does not require gear changes.
* This lathe can turn up to 200 kinds of metric, whitworth, module & DP threads.
* Auto stop device and footbrake offer quick & effective stopping.
LATHE: D-660 660 X 3000 x 105MM BORE Optiturn
SKU:
L--120426
$38,000.00
* This lathe sits on a heavy cast iron base with hardened & ground headstock headstock gears and bedway.
* 105mm spinlde bore allows for large diameter shafts to pass through the headstock.
* Very heavy machine and rigid under all conditions.
* Rapid feeds and left hand wheel.
* Huge range of thread cutting available.
* Fitted with Sino 2 axis digital readout, taper turning attachment & quickchange toolpost.
* Coming from one of the best lathe factories in China, this machine will produce high quality components.
LATHE: C6266C 660 X 2000 X 105MM BORE
SKU:
L--120441
$34,000.00
* Supersonic frequency hardened bedways.
* Hardened & ground headstock gears.
* Triple headstock spindle bearings.
* 105mm spindle bore for turning large shafts.
* Fitted with a powerful 9kW motor.
* No gear changing required to cut metric & imperial threads.
* Fitted with Sino 2 axis digital readout, taper turning attachment & quickchange toolpost.
