| MODEL | SCLCR 1212-F09 |
|---|---|
| ANGLE | 95 Degrees Right Hand |
| SHANK SIZE | 12.0 x 12.0mm |
| TOOL SIZE | F09 |
| INSERT TYPE | CCMT 09T3 |
| WEIGHT NETT/GROSS | 0.1kg/ 0.12kg |
| VOLUME | 0.0001cm |
| INSERT CODE | LTT800278 |
Description
SKU : LTH610172
Price per Unit
$102.40 (Exc GST)
$117.76 (Inc GST)
FEATURES:
Characteristics: * Multipurpose toolholder equipped with rhombic positive insert (angle 80 degrees) * The centre screw ensures good rigidity and chip flow *
Applications: * External turning toolholder for general applications, roughing, semi-finishing and finishing * Negative inserts toolholders Ref MCLN-K or MCLN or PCLN *
| Weight | 0.12 kg |
|---|---|
| Dimensions | 0.12 × 0.025 × 0.025 cm |
