| Swing Over Bed (mm) | 240 |
|---|---|
| Swing Over X-slide (mm) | 135 |
| Swing Over Gap (mm) | N/A |
| Between Centres (mm) | 750 |
| Bed Width (mm) | 135 |
| Spindle Nose | Threaded |
| Speeds (no.) | Variable |
| Speed Range (rpm) | 50 – 2,000 |
| Spindle Bore (mm) | 26 |
| Spindle Taper | MT3 |
| Metric Threading (M) | 0.4 – 3.5 |
| Imperial Threading (tpi) | 8 – 56 |
| Tailstock Taper | MT2 |
| Tool Height (mm) | 12 |
| Motor (kW) | 0.75 |
| Voltage (V) | 230 |
| Weight Nett / Gross (kg) | 170Kgs |
| Volume (m³) | 0.590m³ |
| Packing Size L x W x H (mm) |
Description
SKU : L--165270
Price per Unit
$1,650.00 (Exc GST)
$1,897.50 (Inc GST)
FEATURES:
* V-way bed is hardened & precision ground.
* Spindle is supported by a precision tapered roller bearing.
* MT3 spindle taper gets more capacity.
* Powered longitudinal feed for threading.
* Adjustable gibs for slideways.
* Right land & left hand thread cutting is available.
* Tailstock can be offset for taper turning.
* Equipped with high quality gearbox belt & control board.
* Stand is sold seperately.
| Weight | 120 kg |
|---|
Specifications
Description
Reviews (0)
Shipping & Delivery
Related products
LATHE: GOSAN 1760A 7.5HP
SKU:
L--109180
* Heavy duty geared head lathe, with hardened and ground gears.
* 3-point supported spindle using 2 precision taper roller bearings and 1 ball bearing.
* Spray lubrication system used for headstock.
* One shot lubrication pump for cross slide and bed-ways.
* Quick-change universal gearbox for inch, metric, DP and MP threading.
* Adjustable overload clutch in apron ensures proper cutting load.
* Cross slide screw is permanently immersed in oil and supported by thrust bearing.
* One piece base casting for maximum rigidity.
LATHE: GOSAN 2060 10HP
SKU:
L--109232
* Heavy duty geared head lathe, with hardened and ground gears.
* 3-point supported spindle using 2 precision taper roller bearings and 1 ball bearing.
* Spray lubrication system used for headstock.
* One shot lubrication pump for cross slide and bed-ways.
* Quick-change universal gearbox for inch, metric, DP and MP threading.
* Adjustable overload clutch in apron ensures proper cutting load.
* Cross slide screw is permanently immersed in oil and supported by thrust bearing.
* One piece base casting for maximum rigidity.
LATHE: JESSEY STUDTURN 1430 (TAIWAN)
SKU:
L--110140
* Rigid construction beds are induction hardened and precision ground.
* Harden and ground spindle & gears in headstock for high speed running with low noise.
* Optional two-speed motor with 16 speeds, 35 - 2000rpm.
* Optional variable speed motor, 35 - 2500rpm.
* Smooth, easy speed change selection.
* Feed rod fitted with an overload clutch for safety.
* Comprehensive range of metric, imperial, diametral & modular threads.
* Fitted with 2 axis digital readout & quickchange toolpost.
* Made in Taiwan.
LATHE: GLH-330 330 X 750 X 38MM 1 PHASE (NEW)
SKU:
L--120468H
* New Model
* Precision ground and supersonic frequency hardened bedways.
* The spindle is supported with precision roller bearings.
* Head stock gears are made of high quality steel ground and hardened.
* Sealed and easy operating feed box has various feeds and thread cutting functions.
* ASA D1-4 camlock spindle nose.
* Machine is fitted with foot brake & work lamp for extra safety.
* Short bed length and space saving for training institutions.
* Fitted with safety chuck guard.
* Emergency stop buttons both ends of chip tray
LATHE: BL-1440D 360 X 1000 X 38MM BORE 1 PHASE
SKU:
L--120518
* Induction hardened & precision ground V-way beds.
* Spindle supported by high quality taper roller bearings.
* Sino 2 axis digital readout.
* Coolant pump & tank system.
* Large range of speeds and thread cutting options.
* Fitted with a work lamp & foot brake for added safety.
* Quickchange toolpost for speedy tool changing.
* Gap bed for larger diameter work pieces.
* Carriage mounted spindle control lever.
* Auto feed & threading fully interlocked.
* Tailstock can be offset for turning tapers.
* This lathe is available with an imperial leadscrew, indent only.
LATHE: WBL-835 180 X 350 X 20MM BORE V/SPEED 1 PHASE
SKU:
L--165150
* Variable speed control board offering a wide range of speeds without gear change.
* The bedways are hardened and ground for lasting accuracy and durability.
* Adjustable gibs on slideways.
* Tailstock can be offset for taper turning.
* Fitted with reverse switch for added versatility.
* Equipped with emergency stop button for added safety.
* Ideal hobby lathe - easy to opperate - easy to store.
* Stand is sold seperately.
LATHE: WM-250GN 250 X 500 X 26MM BORE (NEW MODEL) 1 PH
SKU:
L--165262
* New model, one of our most popular lathes with new modifications.
* Induction hardened & precision ground V-way beds.
* Tailstocks can be offset for turning tapers.
* Stand alone coolant pump & tank system.
* Handy LED lamp located in the middle of splashguard.
* Includes change gears for metric & imperial threading.
* Righthand & lefthand thread cutting is available.
* Spindle supported by high precision bearings.
* Adjustable gibs for slideways.
* Also available with powered cross slide & longitudinal feed.
* Stand is sold seperately.
LATHE: SHOPTURN-280G 280 X 650 X 26MM BORE G/HEAD 1 PHASE
SKU:
L--165278
* Compact lgeared Head Lathe with 12 speed precision ground gears
* Induction hardened & precision ground bedways.
* Headstock is gear driven in oil bath.
* Forward/reverse & emergency stop switches.
* Tailstock can be offset for turning tapers.
* Covered leadscrews & limit switches for safety.
* Metric & imperial threading dial indicator.
* Extra wide bedway for more capacity.
* Ideal for hobbyists and small workshops.
* Stand is sold seperately.
