| Table Size (mm) | 800 x 240 |
|---|---|
| Drilling Capacity (mm) | 32 |
| Travel X-axis (mm) | 500 |
| Travel Y-axis (mm) | 230 |
| Swing (mm) | 440 |
| Max Nose to Table (mm) | 450 |
| Spindle Taper | MT4 |
| Quill Stroke (mm) | 120 |
| Quill Diameter (mm) | 75 |
| Column Diameter (mm) | Dovetail |
| Speeds (no.) | 6 |
| Speed Range (rpm) | 75 – 1600 |
| Table Size (mm) | 14 |
| Motor (kW) | 1.1 |
| Voltage (V) | 230 |
| Weight Nett / Gross (kg) | 300 / 330 |
| Volume (m³) | 0.7429 |
| Packing Size L x W x H (mm) | 850 x 760 x 1150 |
| Stand Weight (kg) | 42 |
| Volume | 0.186 |
Description
SKU : MD-330290
Price per Unit
$5,300.00 (Exc GST)
$6,095.00 (Inc GST)
FEATURES:
* Precision mill, quiet & smooth running, yet solid & stable.
* Heavy cast square section column with dovetail slideway.
* Covers on both vertical & horizontal slideways.
* Head can be tilted ±90°.
* Fine down feed adjustment.
* Forward & reverse magnetic safety switch.
* Recycling coolant system with filters.
* Adjustable table travel stops.
* Adjustable depth gauge.
* Mounted on a heavy duty stand.
