| Table Size (mm) | 800 x 210 |
|---|---|
| Drilling Capacity (mm) | 32 |
| Travel X-axis (mm) | 580 |
| Travel Y-axis (mm) | 200 |
| Swing (mm) | 380 |
| Max Nose to Table (mm) | 470 |
| Spindle Taper | MT3 |
| Quill Stroke (mm) | 70 |
| Quill Diameter (mm) | 70 |
| Column Diameter (mm) | Dovetal |
| Speeds (no.) | Variable |
| Speed Range (rpm) | 60 – 4000 |
| Table Slot (mm) | 14 |
| Motor (kW) | 1.5 |
| Voltage (V) | 230 |
| Weight Nett / Gross (kg) | 240 / 280 |
| Volume (m³) | 0.8473 |
| Stand Weight (kg) | 30.0 |
| Stand Volume (m³) | 0.1488 |
MILL DRILL: WMD-30V 1.5HP 1PH WEISS
$3,100.00
MILL/DRILL: TPC-25 1HP 1PH WEISS
$2,500.00
Description
SKU : MD-330424
Price per Unit
$2,690.00 (Exc GST)
$3,093.50 (Inc GST)
FEATURES:
* The WMD-32B is a compact milling & drilling machine with a variable speed control offering speeds from 0 to 2250rpm with a turn of a dial.
* This machine features a brushless motor which offers consistant torque at all speeds.
* Spindle is supported by high speed taper roller bearings.
* The geared head provides greater torque and quite running.
* Head is raised by handwheel on column with dovetail ways.
* Head can be tilted to 90°.
* This is an ideal machine for modelmakers or any small workshop.
| Weight | 280 kg |
|---|---|
| Dimensions | 0.85 × 0.89 × 1.12 cm |
Specifications
Description
Reviews (0)
Shipping & Delivery
Related products
MILL/DRILL: TPC-32 1.5HP 1PH WEISS
SKU:
MD-330260
MILL/DRILL: WMD-45AV VARIABLE SPEED DRO P/FEED WEISS
SKU:
MD-330285W
* Precision mills, quiet & smooth running, yet solid & stable.
* Heavy cast square section column with dovetail slideway.
* Covers on both vertical & horizontal slideways.
* Heads can be tilted ±90°.
* Fine down feed adjustment.
* Forward & reverse magnetic safety switch.
* Recycling coolant system with filters.
* Adjustable table travel stops.
* Powerfeed on X-axis.
* Control box on swivel arm.
* Electrical box on back of column.
* Powered rise & fall of the milling head.
* Fitted with DRO
MILL/DRILL: ZX-40BPC COLUMN WEISS
SKU:
MD-330382
* The ZX-40APC is a robust column type mill driill.
* Head can be rotated 360° and can be tilted to 45°.
* Equipped with power downfeed on the quill and a MT4 spindle taper.
* The compound table makes this a very verisatile machine.
* Coolant system with reservoir built into the base of the machine.
MILL/DRILL: WBM-16A V/SPEED BRUSHLESS MOTOR WEISS
SKU:
MD-330396
* Compact milling & drilling machine with variable speed control.
* Brushless motor provides more power & less maintenance.
* Motor control board manufactured in the U.S.A.
* Digital displays for both speed & depth.
* Geared head for greater torque & quiet running.
* Head is raised & lowered on the dovetail column using a handwheel.
* Spindle is supported by high speed taper roller bearings.
* Fine down feed adjustment.
* Heads can be tilted ±90°.
* These models are ideal for hobbyists and small workshops.
MILL/DRILL: WMD-20L V/SPEED WEISS
SKU:
MD-330400
* Compact milling & drilling machine with variable speed control.
* Brushless motor provides more power & less maintenance.
* Motor control board manufactured in the U.S.A.
* Digital displays for both speed & depth.
* Geared head for greater torque & quiet running.
* Head is raised & lowered on the dovetail column using a handwheel.
* Spindle is supported by high speed taper roller bearings.
* Fine down feed adjustment.
* Heads can be tilted ±90°.
* These models are ideal for hobbyists and small workshops.
MILL/DRILL: WBM-20L V/SPEED BRUSHLESS MOTOR WEISS
SKU:
MD-330402
* The WMD20L is a compact milling & drilling machine with a variable speed control offering speeds from 0 to 2250rpm with a turn of a dial.
* This machine features the new brushless motor which offers more torque than the old model.
* Spindle is supported by high speed taper roller bearings.
* The geared head provides greater torque and quite running.
* Head is raised by handwheel on column with dovetail ways.
* Head can be tilted to 90°.
* This is an ideal machine for modelmakers or any small workshop.
MILL DRILL: WMD-30V 1.5HP 1PH WEISS
SKU:
MD-330422
* The WMD30V is a compact milling & drilling machine with a variable speed control offering speeds from 0 to 2250rpm with a turn of a dial.
* This machine features a brushless motor which offers consistant torque at all speeds.
* Spindle is supported by high speed taper roller bearings.
* The geared head provides greater torque and quite running.
* Head is raised by handwheel on column with dovetail ways.
* Head can be tilted to 90°.
* This is an ideal machine for modelmakers or any small workshop.
MILL DRILL: ZX-32G/A 1HP 1PH
SKU:
MD-330428
* The ZX32G is a compact milling & drilling machine with a variable speed control offering speeds from 0 to 2250rpm with a turn of a dial.
* This machine features a brushless motor which offers consistant torque at all speeds.
* Spindle is supported by high speed taper roller bearings.
* The geared head provides greater torque and quite running.
* Head is raised by handwheel on column with dovetail ways.
* Head can be tilted to 90°.
* This is an ideal machine for modelmakers or any small workshop.
