| Table Size (mm) | 800 x 230 |
|---|---|
| Travel X-axis (mm) | 400 |
| Travel Y-axis (mm) | 230 |
| Travel Z-axis (mm) | 380 |
| Quill Stroke (mm) | 120 |
| Quill Diameter (mm) | 86 |
| Nose to Column (mm) | 145 – 550 |
| Nose to Table (mm) | 70 – 420 |
| Spindle Taper (vert & horz) | NT40 |
| Vertical Speed Range (rpm) | 115 – 1750 |
| Horizontal Speed Range (mm) | 60 – 1350 |
| Table Slot (mm) | 14 |
| Vertical Motor (kW) | 1.5 |
| Horizontal Motor (kW) | 1.5 |
| Voltage (V) | 415 |
| Weight Nett / Gross (kg) | 880 / 1000 |
| Volume | 3.146cm |
| Packing Size L x W x H (mm) | 1,300 x 1,100 x 2,200 |
Description
SKU : MM-280825
Price per Unit
$9,700.00 (Exc GST)
$11,155.00 (Inc GST)
FEATURES:
* Ideal small workshop machine for both horizontal and vertical milling.
* Vertical head tilts left and right 90°
* Geared head on vertical spindle makes speed changes quick and easy.
* Belt driven on horizontal spindle.
* Dovetail guide ways on all axis for rigidity.
* Swivel table for universal applications.
* Forward/reverse-on/off switch on front panel.
* Comprehensive accessory kit makes this mill very cost effective.
| Weight | 1000 kg |
|---|---|
| Dimensions | 1.3 × 1.1 × 2.2 cm |
