DESCRIPTION | TP-1040F Planer |
---|---|
MAX CUTTING WIDTH | 380mm |
MAX CUTTING HEIGHT | 200mm |
MIN WORKING LENGTH | 160mm |
MAX CUTTING DEPTH | 5.0mm |
FEED SPEEDS | 9.1m/sec |
TABLE SIZE | 453 x 406mm |
CUTTER HEAD | 4pc Blades – 400 x 25 x 3.0mm |
CUTTER HEAD SPEED | 4500rpm |
MOTOR | 2.2kw 1 Phase 230v |
INFEED ROOLS | Serrated Steel |
WEIGHT NETT/GROSS | 212/240kg |
VOLUME | 0.5995cm |
PACKING SIZE L X W X H | 830 X 620 X 1165mm |
Description
SKU : TKN112618
Price per Unit
$3,300.00 (Exc GST)
$3,795.00 (Inc GST)
FEATURES:
* This Tanner TP-1040F 16″ Planer comes with a 2.2kw motor
* Equiped wilh 3 blade cutter head
* Serrated steel infeed rollers
* The machine is equiped with anti-kickback fingers for operator safety
* Large extension infeed and outfeed table are fitted allowing for maximum workpiece support
* Fully enclosed carbnet stand
Weight | 240 kg |
---|---|
Dimensions | 0.83 × 0.62 × 1.165 cm |
Specifications
Description
Reviews (0)
Be the first to review “PLANER: TANNER 16″ 2.2KW 1PH MOTOR UNDER” Cancel reply
Shipping & Delivery
Related products
PLANER: TANNER 16″ tp-104H 4KW 3PH SPIRAL HEAD
SKU:
TKN112614
$6,300.00
* This Tanner TP-104H 16" Planer comes with a 4.0kw motor
* Equiped wilh a spiral cutterhead
* Serrated steel infeed rollers
* The machine is equiped with anti-kickback fingers for operator safety
* Large extension infeed and outfeed table are fitted allowing for maximum workpiece support
* Oil bath gearbox for feed speed change
* Fully enclosed carbnet stand
* Heavy duty machine
PLANER: TANNER TH410A 16″ 3HP 1PH INDUSTRIAL S/HEAD
SKU:
TKN112620
$5,807.00
* This Tanner 16: Industrial Planer comes with a 3.0hp single phase motor
* Equiped wilh three knife 72.0mm cutterhead
* Serrated steel infeed rollers
* The machine is equiped with anti-kickback fingers for operator safety
* Large extension infeed and outfeed table are fitted allowing for maximum workpiece support
* Oil bath gearbox for feed speed change
* Heavy cast iron table
* Top mounted dust chute
PLANER: TANNER TK-201F 20″ 5HP 3PH INDUSTRIAL S/HEAD
SKU:
TKN114238
$5,900.00
* The TANNER TK-201F Industrial offers a cutting capacity up to 20"
* Cutting depth of 6.0mm
* Solid cast construction make this machine very rigid
* Heavy columns suport the cutterhead
* Oil bath lubricating gearbox provides very smooth feeding
* Both infeed and outfeed tables are heavy cast to provide support to the workpiece
* Two rollers are built on top of the machine offering convenient material handling
* This model has a 5hp three phase motor
* This model is fitted with a Spiral Cutterhead
* This head is dynamically balanced to provide smooth running, low noise output and a good finish to the workpiece
PLANER: TANNER TP-106J 610MM 5.5KW 3PH SPIRAL CUTTER HEAD
SKU:
TKN114335
$9,500.00
* TANNER WT-610 Planer with 610mm planing width
* Industrial quality machine
* Fitted with spiral cutter head
* 3pcs motor-driven upper feed rollers
* Rubber-coated outfeed rollers to endure a perfect feeding in any conditions
* Partial view of cutterblock and feed system
* Powerful 5.5hp main motor (10hp is optional)
* Cutterblock with antikick-back guards
PLANER: TANNER WT-760 760MM 20HP SPIRAL HEAD
SKU:
TKN114340
$19,840.00
* TANNER WT-760 Planer with 760mm planing width
* Industrial quality machine
* Fitted with spiral cutter head
* 3pcs motor-driven upper feed rollers
* Rubber-coated outfeed rollers to endure a perfect feeding in any conditions
* Partial view of cutterblock and feed system
* Powerful 20hp main motor
* Power rise & fall
* Cutterblock with antikick-back guards
PLANER: TANNER TP-304 600MM 3 SIDER SPIRAL HEADS
SKU:
TKN114358
$0.00
* TANNER WT-760 Planer with 760mm planing width
* Industrial quality machine
* Fitted with spiral cutter head
* 3pcs motor-driven upper feed rollers
* Rubber-coated outfeed rollers to endure a perfect feeding in any conditions
* Partial view of cutterblock and feed system
* Powerful 20hp main motor
* Power rise & fall
* Cutterblock with antikick-back guards
PLANER: TANNER FOUR SIDER 230MM 10HP
SKU:
TKN115000
$75,000.00
* TANNER MS-423 4 side Planer
* Industrial quality machine with table surface of high ductile cast iron
* Cutterhead guard is manufactured from HSS, heat treated and hard chromed
* Numerical control panel allows sizing adjustment of cutters for convenience and rapit settings
* Fitted with overload protection - cutter will stop within 3 seconds !
* Feeding roller is combined with pneumatic and gearbox feed system
* Feeding can be opperated in jog mode for accurate settings
* The table surface adops a newly designed pneumatic lubrication for feeding all types of timber
PLANER: TANNER FOUR SIDER 300MM 7.5HP
SKU:
TKN115020
$56,000.00
* TANNER M-412 side Planer
* Industrial quality machine with table surface of high ductile cast iron
* Cutterhead guard is manufactured from HSS, heat treated
* Numerical control panel allows sizing adjustment of cutters for convenience and rapit settings
* Fitted with overload protection
* Feeding can be opperated in jog mode for accurate settings
Three phase motor drive.
Powerful motor drive for each spindle.
Digital position control for accurate and easy setting.
7,000 rpm high spindle speed.
Compact construction. Maximum stability.
Variable feed speed.
See-thru top guard.
