CUTTING WIDTH | 508mm |
---|---|
CUTTING HEIGHT | 200mm |
MIN LENGTH | 170mm |
MIN THICKNESS | 6.0mm |
FEED SPEEDS | 2 |
FEED RATE | 5-10M/Pm |
CUTTER HEAD | 80.0mm |
INSERTS MODEL | |
TABLE SIZE | 710 X 508mm |
SPEED | 5000rpm |
MOTOR | 5hp 3 Phase |
WEIGHT NETT/GROSS | 392kg |
VOLUME | 0.8447cm |
PACKING SIZE L X W X H |
Availability : Enquire Now
Price per Unit
ex-gst
$5,900.00Inc-gst
$6,785.00PLANER: TANNER TK-201F 20" 5HP 3PH INDUSTRIAL S/HEAD
Description
SKU : TKN114238
Price per Unit
$5,900.00 (Exc GST)
$6,785.00 (Inc GST)
FEATURES:
* The TANNER TK-201F Industrial offers a cutting capacity up to 20″
* Cutting depth of 6.0mm
* Solid cast construction make this machine very rigid
* Heavy columns suport the cutterhead
* Oil bath lubricating gearbox provides very smooth feeding
* Both infeed and outfeed tables are heavy cast to provide support to the workpiece
* Two rollers are built on top of the machine offering convenient material handling
* This model has a 5hp three phase motor
* This model is fitted with a Spiral Cutterhead
* This head is dynamically balanced to provide smooth running, low noise output and a good finish to the workpiece
Weight | 392 kg |
---|---|
Dimensions | 0.95 × 0.76 × 1.17 cm |
Specifications
Description
Reviews (0)
Be the first to review “PLANER: TANNER TK-201F 20″ 5HP 3PH INDUSTRIAL S/HEAD” Cancel reply
Shipping & Delivery
Related products
PLANER: TANNER TH410A 16″ 3HP 1PH INDUSTRIAL S/HEAD
SKU:
TKN112620
$5,807.00
* This Tanner 16: Industrial Planer comes with a 3.0hp single phase motor
* Equiped wilh three knife 72.0mm cutterhead
* Serrated steel infeed rollers
* The machine is equiped with anti-kickback fingers for operator safety
* Large extension infeed and outfeed table are fitted allowing for maximum workpiece support
* Oil bath gearbox for feed speed change
* Heavy cast iron table
* Top mounted dust chute
PLANER: TANNER CT-508 20″ 3HP 1 PHASE
SKU:
TKN114210
$4,200.00
* The TANNER CT-508 20 Planer provides a cutting capacity of up to 20" wide
* Maximum planing thickness is 6.0mm
* With rollers situated on the top of the machine allows stock to pass over the machine
* Using the in-feed and out-feed roller support operation is easy and convenient
* An oil-bath lubricated gear box provides very smooth feeding
* Lifting lever is provided to allow for easy maneuverability
* The unit is the result of quality engineering which meets with CSA standards
* All components precision machined for complete interchangeability and added value
* A rugged machine which has been proven in the field for many years
PLANER: TANNER D52 520MM 5.5KW 3PH SPIRAL CUTTER HEAD
SKU:
TKN114320
$0.00
* TANNER D52 Planer with 520mm planing width
* Industrial quality machine
* Fitted with spiral cutter head
* 3pcs motor-driven upper feed rollers
* Rubber-coated outfeed rollers to endure a perfect feeding in any conditions
* Partial view of cutterblock and feed system
* Powerful 5.5hp main motor (10hp is optional)
* Cutterblock with antikick-back guards
PLANER: TANNER WT-760 760MM 20HP SPIRAL HEAD
SKU:
TKN114340
$19,840.00
* TANNER WT-760 Planer with 760mm planing width
* Industrial quality machine
* Fitted with spiral cutter head
* 3pcs motor-driven upper feed rollers
* Rubber-coated outfeed rollers to endure a perfect feeding in any conditions
* Partial view of cutterblock and feed system
* Powerful 20hp main motor
* Power rise & fall
* Cutterblock with antikick-back guards
PLANER: TANNER TP-208 800MM 2 SIDER SPIRAL HEADS
SKU:
TKN114356
$1,690.00
* TANNER YP208 Planer with 800mm planing width
* Industrial quality machine
* Fitted with spiral cutter head
* 3pcs motor-driven upper feed rollers
* Rubber-coated outfeed rollers to endure a perfect feeding in any conditions
* Partial view of cutterblock and feed system
* Powerful 20hp main motor
* Power rise & fall
* Cutterblock with antikick-back guards
PLANER: TANNER TP-304 600MM 3 SIDER SPIRAL HEADS
