* Hydraulic / Mechanical ram, synchronised positive stop design, ram stroke controlled by precision mechanical nut depth stops built into each cylinder. * Electronically controlled by Estun E200 programmable digital controlller assuring accuraterepeatability. * Hardened ball screw on back gauge with manual crowning arrangement. * Front support can be easily adjusted and moved depending on the sheet width. * Hydraulic MPA pressure gauge mounted on right side of support frame with quick adjusting pressure control knob allowing operator to accurately set the pressure required for different material thickness, incorporating with hydraulic overload protection. * Enclosed rear gate with micro safety switches complete with sliding rear door for easy access. * Conveniently mounted control box on pendant for quick swivel and adjustments. * Welded steel fabricated synchronised torsion bar horizontally supporting main bending beam to provide consistent parallelism that also can be adjusted for taper correction.

* Hydraulic / Mechanical ram, synchronised positive stop design * Ram stroke controlled by precision mechanical nut depth stops built into each cylinder * Electronically controlled by Estun E200 programmable digital controlller assuring accuraterepeatability * Hardened ball screw on back gauge with manual crowning arrangement * Front support can be easily adjusted and moved depending on the sheet width * Hydraulic MPA pressure gauge mounted on right side of support frame * With quick adjusting pressure control knob allowing operator to accurately set the pressure required for different material thickness * Incorporating with hydraulic overload protection * Enclosed rear gate with micro safety switches complete with sliding rear door for easy access * Conveniently mounted control box on pendant for quick swivel and adjustments * Welded steel fabricated synchronised torsion bar horizontally supporting main bending beam to provide consistent parallelism that also can be adjusted for taper correction.

* Strong welded steel structure Stress relieved to improve stability * Torsion shaft forced synchronisation of mechanical limit stopper balance * Intergrated hydraulic system can accomodate large range of speed regulation * Delem Touch screen Controller DA66T. * Akas (Germany) CE Laser guard * Front support moveable on guide rails * Quick clamping top tool. Bottom tool on guide rails * Segmented top and bottom tool.

* With Super Custom you can form even the biggest structures,with the highest speed and versatility. * 1300-mm daylight and 900-mm tool adapters * Bend boxes up to 600-mm deep * 400-mm stroke * Extract pieces easily * Active real-time crowning * Straight profiles with any material * 3D file import and 2D blank output * A bridge between design and other machinery * AirSlide sliding tool adapters and clamping * Quick and flexible tooling * ECO/ECO+ package * Increase speed and reduce consumption * GPS4 angle control * Accurate bends on the first try * Wireless foot pedal * No cables on the floor. * Assistance and connectivity * With our Service you're in good hands * Any tonnage and size up to 2500 tons/14 m and beyond * Custom daylights and strokes * Tailored around your needs * Industry 4.0 Ready * Data analysis and predictive maintenance
