* Hydraulic / Mechanical ram, synchronised positive stop design * Ram stroke controlled by precision mechanical nut depth stops built into each cylinder * Electronically controlled by Estun E200 programmable digital controlller assuring accuraterepeatability * Hardened ball screw on back gauge with manual crowning arrangement * Front support can be easily adjusted and moved depending on the sheet width * Hydraulic MPA pressure gauge mounted on right side of support frame * With quick adjusting pressure control knob allowing operator to accurately set the pressure required for different material thickness * Incorporating with hydraulic overload protection * Enclosed rear gate with micro safety switches complete with sliding rear door for easy access * Conveniently mounted control box on pendant for quick swivel and adjustments * Welded steel fabricated synchronised torsion bar horizontally supporting main bending beam to provide consistent parallelism that also can be adjusted for taper correction.

* Strong welded steel structure * Stress relieved to improve stability * Torsion shaft forced synchronisation of mechanical limit stopper balance * Intergrated hydraulic system can accomodate large range of speed regulation * Delem DA56 controller, Akas laser safe system * One set of Top and Bottom tool * Front support on guide rails * Hydraulic crowning.

* If you are looking for a tough and simple press brake, Gasparini X-Press Easy is the answer. It's the ideal machine for the most common processes without forgoing Italian manufacturing and high-quality components. * X-Press Easy has what it takes to win over those who want a fast return on investment without lowering production quality. * Ram speed 200 mm/s (~8 in/s), X-axis speed 500 mm/s (~20 in/s) * DSP-AP laser safety: lowered speed change point and auto-blanking for box bending * 4 axes Y1Y2-X-R, with 6-axes option adding Z1-Z2 * Manual or pneumatic upper and lower clampings * Customizable daylight and stroke * Updated design * New coded security doors * High-gloss anti-dirt water-based paint * Frame produced in Italy by Gasparini, accurately dimensioned through FEA * Bosch-Rexroth hydraulic valve block, pump and valves * Heidenhain linear optical encoder with 1-µm resolution * Bosch linear bearings, Gudel racks and pinions * Panasonic brushless motors and drives

* The flexible alternative to roll forming lines * Remote programming * Machine sensorization * Predictive maintenance * ERP, CAD-CAM, NAS, LAN integration * Automatic tool change * Sheet loading/unloading * Sheet picking and thickness check * Smart positioning * K-factor autodetection * 24/7 unattended operation * Usage stats * Interface with warehouse, laser cutting, welding * Anomaly detection * Embedded quality check * Remote assistance and control * Material variability compensation * Cycle times and errors analysis * Suitable for panels of various sizes * Automatic compensation of machine deformation.
