* This clamp is supplied with spindle assembly and red vinyl hand grip * Holding capacity 180kg * Handle is in a vertical position when clamped * Spindle is fitted with rubber holding pad

* The GH-302F clamp is suitable for light medium duty operations * Each clamp is supplied with a pressed steel base * Close tolerances between the base and plunger allow these clamps to be used for pin locating gauges as well as clamping devices * These clamps are supplied with adjustable end screw for fine adjustment * The GH-302F clamp is supplied with red vinyl hand grip * Holding capacity is 136kg * Stroke is 25.0mm with handle locking in a 45deg position

* The GH-304H clamp is suitable for light medium or heavy duty operations * Each clamp is supplied with a ductile iron base, precision machined for flatness * Close tolerances between the base and plunger allow these clamps to be used for pin locating gauges as well as clamping devices * Plunger locks in extended or retracted position * These clamps are supplied with adjustable end screw for fine adjustment * The GH-304H clamp is supplied with red vinyl hand grip * Holding capacity is 680kg

* Through mount clamp with handle in a down position when clamped *
