| DESCRIPTION | Super Index Spacer |
|---|---|
| SIZE | 6″ |
| CHUCK | 160mm 3 Jaw |
| HEIGHT | |
| APPLICATION | Indexing |
| WEIGHT NETT/GROSS | |
| VOLUME |
Description
SKU : IF-134600
Price per Unit
$1,450.00 (Exc GST)
$1,667.50 (Inc GST)
FEATURES:
* This index combines the advantages of the Super Index with those of a worm-geared index.
When mounted on a milling, boring or other machine tool it can carry out single-purpose indexing and indirect indexing using the worm-drive mechanism * Disengaging the worm drive the 24-notch master plate permits 2,3,4,6,8,12 and 24 dividing in the same manner as the Simple Index * When the chuck is removed, the unit can be used as a horizontal and vertical type rotary table * The operating handle to rotary table worm gear reduction ration is 1:90.
The operating handle collar is graduated in in one minute, and readings down to ten seconds can be set on the vernier*
