| DESCRIPTION: | Thread rolling Machine |
|---|---|
| MODEL: | PR-60A |
| MAX DIAMETER: | 100.0mm |
| MIN DIAMETER: | 18.0mm |
| RANGE IF INFEED LENGTH: | 50.0mm |
| RANGE OF THRU-FEED: | Free |
| SPEED RANGE: | 130 – 450rpm |
| MAX DIA ROLLING DIES: | *120mm |
| DISTANCE DIES SPINDLE: | Max 210mm – Min 90mm |
| MAX ROLLING PRESSURE: | 20 Tons |
| MAIN POWER: | 3.75kw |
| HYDRAULIC POWER: | 2.2kw |
| COOLANT: | 1/8hp |
| HEIGHT TO CENTRE SPINDLE: | 950mm |
| O/A HEIGHT: | 1450mm |
| WEIGHT NETT/GROSS | 1150/1400kg |
| VOLUME: | 2.2656cm |
Description
SKU : TRM100262
Price per Unit
$49,870.00 (Exc GST)
$57,350.50 (Inc GST)
FEATURES:
* This PR-30A thread rolling machine is the smallest in the range
* other models are available with a maximum range of 100mm
| Weight | 1400 kg |
|---|---|
| Dimensions | 1.25 × 1.25 × 1.45 cm |
