* These Ai Power WI-415 Arc Welders are manufactured from quality materials *
* Recitier is 1GBT
* Intekigent digital core precision regulation .
* Functional diversication ( Thust + thermal arc )
* Ignition + anti-sticking + memory.
* Output current/ double display.
* Suporting generator matching mode.
* Equal current output with different input voltage.
* Automatic start and stop fan for energy saving and high efficiency.
* Overall protection of chassis.

Weight	11.8 kg
Dimensions	0.445 × 0.205 × 0.35 cm

Compare

Add to wishlist

Specifications

Description

DESCRIPTION	Global Arc Welder
INPUT RANGE	AC 230v
VOLTAGE RANGE	AC 120-560v
RATED INPUT POWER (KW)	10.0
OUTPUT CURRENT RANGE (A)	30-260A
DUTY CYCLE (% @ 40DEG C )	40%
POWER FACTOR (COS)	0.7
NO-LOAD VOLTAGE (V)	65 – 75v
iNSULATION CLASS	F
EFFICENCY (%)	60
ELECTRODE (MM)	1.6 – 5.0
PROTECTION CLASS	IP21S
WEIGHT NETT/GROSS	11.8/12.5kg
VOLUME	0.0319cm
